Product Details:
|
| Display Brightness: | 800 Cd/m² (Sunlight Readable) | Display Size: | 7-inch (1024 × 600) |
|---|---|---|---|
| Processor: | Quad-Core RK3566 1.8GHz | Operating System: | Android 11 (Industrial-Grade) |
| Memory: | 4GB/8GB LPDDR4 (Configurable) | Storage: | 16GB-64GB EMMC (Expandable) |
| Connectivity: | 4G/WiFi/BT Optional (IoT Ready) | Operating Temp.: | -20°C To +70°C (Industrial Range) |
| ESD Protection: | ±8kV Air/±6kV Contact Discharge | Power Input: | 24V DC (Industrial Standard) |
| GPU: | Mali-G52 (3D Acceleration) | RTC Features: | Timed On/Off + Real-Time Clock |
| Surface Hardness: | ≥6H (Anti-Scratch Coating) | System Upgrade: | Local USB Flash Support |
| Touch Technology: | 10-Point Capacitive (Glove/Wet Operation) | Compliance: | RoHS, REACH (EU/US Pre-Certified) |
| Highlight: | 800nits Industrial Android TFT Display,4G Industrial Android TFT Display,WiFi Industrial Android TFT Display |
||
All-in-One Industrial Android Computer for Harsh EU/US Environments
The SFEM700JX-7329ACT integrates a high-brightness 7" TFT display with a quad-core Android computer, engineered for North American and European industrial automation. Featuring 800nits sunlight-readable brightness, -20°C cold-start capability, and optional 4G connectivity, this embedded module delivers unmatched reliability for factory HMIs, transportation systems, and outdoor kiosks. Preloaded with Android 11 OS and industrial-grade ESD protection (±8kV), it meets stringent EU/US operational standards.
Key Advantages for Industrial OEMs:
✅ 800nits Display – Visible under direct sunlight (construction/agriculture)
✅ -20°C Cold Boot – Starts instantly in Nordic winters/US cold storage
✅ Plug-and-Play IoT – Optional 4G/WiFi/BT for IIoT connectivity
Industrial Performance Features
Rugged RK3566 Quad-Core
1.8GHz Cortex-A55 CPU + Mali-G52 GPU handles SCADA, MES, and machine vision applications.
24/7 Operation Ready
-20°C to +70°C operating range with ≤85% humidity resistance (non-condensing).
Secure Android 11 OS
Supports legacy Windows emulation (via APK) and over-the-air updates (local USB drive).
Expandable Memory
Configurable 4GB/8GB RAM + 16GB-64GB storage for data logging and heavy applications.
Technical Superiority
| Industrial Challenge | Our Solution |
|---|---|
| Vibration/EMI interference | Metal enclosure + ±8kV ESD protection |
| Outdoor visibility | 800 cd/m² anti-glare display (6H hardness) |
| Field connectivity | Optional Quectel 4G modules (EU band supported) |
| Power stability | 24V DC input (compatible with DIN-rail PSUs) |
Target Applications
German Industry 4.0: Machine control panels, AGV interfaces
US Transportation: Bus/train infotainment, toll collection systems
UK Energy: Oil rig monitoring displays, wind turbine HMIs
French Retail: Self-checkout kiosks, digital menu boards
Why Global Engineers Trust This System
![]()
Manufactured by Saef Technology, includes:
Industrial Connectivity: RS232/485 via GPIO expansion (not listed but standard in RK3566)
RTC Battery Backup: Critical for automated timed power cycles
Secure Boot: Verified boot chain for industrial security
