FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle

FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle
FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle

Large Image :  FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle

Product Details:
Place of Origin: ShenZhen / China
Brand Name: SAEF
Certification: ISO9001 / ISO14000/FCC, CE, ROHS
Model Number: SF1556X-T
Payment & Shipping Terms:
Minimum Order Quantity: 2 pcs
Price: Negotiable based on order quantity
Packaging Details: Standard Exportation Package
Delivery Time: 1-5 weeks
Payment Terms: L/C,T/T,Western Union,Paypal
Supply Ability: 3000K pcs per month

FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle

Description
Product: 15.6-Inch Portable Monitor Resolution: 1920*1080 Dots
Display Area: 350*200mm (16:9) Panel Type: IPS
Input Interface:: Type-C, Mini HD Refresh Rate: 60Hz
Brightness:: 300cd/m² Output Interface:: 3.5 Mm Headphone Interface
Net Weight:: 645g Gross Weight:: 1450g
Packing Size:: 400*265*65mm Touch Type: Capacitive Touch Screen
Touch Interface: USB
Highlight:

1920*1080 Portable Touch Monitor

,

FHD Portable Touch Monitor

,

15.6-Inch Portable Touch Monitor

Portable 15.6-Inch 60Hz Monitor with FHD 1920*1080 IPS Screen Easy Carry Second Screen for Work Desktop Application


Product Highlights - Why Choose Us?



10-Point Capacitive Touch for Intuitive Interaction

  • Smooth Multi-Touch Experience: Supports up to 10 fingers for seamless navigation, ideal for Windows-based tasks like graphic design, spreadsheet editing, or interactive presentations
  • Plug-and-Play on Windows: Direct compatibility with Windows 7+ systems for instant touch functionality (macOS/iOS/Android support display only, no touch)
  • Gaming-Ready Touch Controls: Enhance gameplay on touch-enabled titles or emulators, providing a modern alternative to traditional keyboards/mice

Stunning Visuals with FHD HDR Display

  • 1920x1080 IPS Panel: Crisp Full HD resolution with 16:9 aspect ratio, delivering vibrant colors (16.7 million) and sharp text for work or entertainment
  • HDR Technology: Elevates contrast (1000:1) and brightness (300 nits) to reveal deeper blacks and brighter highlights in games, movies, and HDR-compatible content
  • 178° Wide Viewing Angle: Maintain color accuracy from any seat, perfect for collaborative work setups or family movie nights

Versatile Stand & VESA Mount Compatibility

  • Adjustable Ergonomic Stand: Tilt, swivel, and fold the monitor for optimal viewing angles (0°-180°), reducing neck strain during long work sessions
  • VESA Mount Support (75x75mm): Convert to a fixed desktop setup or wall-mounted display for permanent workstations or gaming rigs
  • Ultra-Portable Design: Just 655g weight and 17mm thickness, easily fits in a laptop bag for remote work or travel

Multi-Device Connectivity for Any Scenario

  • Dual USB-C & HDMI Ports:
    • USB-C 3.1 (full-function): Transmits power, video, and data from laptops/smartphones (e.g., Samsung DeX, Huawei EMUI)
    • Mini HDMI: Direct connection to gaming consoles (PS5/Switch/Xbox) or legacy devices
  • Universal Compatibility: Works with laptops (Mac/Windows), tablets, smartphones, and gaming consoles – no drivers required
  • Reverse Charging via USB-C: Powers low-consumption devices like smartphones during use (cable included)

Immersive Audio & Flexible Controls

  • Built-in Stereo Speakers (2x2W): Clear audio for meetings, movies, and gaming, with a 3.5mm jack for private listening
  • Physical Control Buttons: Easily adjust volume, switch display modes, or navigate menus via tactile buttons (Volume +/-, Menu, Return)
  • Multi-Language OSD Menu: Choose from English, Chinese, German, Spanish, and more for user-friendly settings management

Reliable Performance & Support

  • Industry Certifications: CE, FCC, and RoHS approved for safety and quality assurance
  • 1-Year Warranty: Global coverage for parts and labor, plus 24/7 customer support
  • Bulk Order Benefits: Customizable logos, packaging, and graphics for businesses or resellers (minimum order quantities apply)





Specifications



Specification Details
Product Model 1556X
Screen Size 15.6
Appearance Dimensions 360mm * 225mm *9mm
Display Area 346mm * 192mm
Screen Type / Viewing Angle IPS 178°
Resolution / Refresh Rate 1920*1080@60Hz
Aspect Ratio 16:9
Contrast Ratio 700:1
Brightness 350cd/m²
Display Colors 16.7M
Color Gamut 45%
Input Current/Voltage 5V2A
Power ≤10W
Buttons Volume +, Volume -, Menu button, Return button
Input Interfaces Type-C*2,Micro USB*1,Mini HDMI
Output Interfaces 3.5 mm headphone jack
Multi-language Support including Chinese, English, German, Korean, French, Spanish, Japanese, etc.
Net Weight 645g
Package Dimensions/Weight (1 Unit) 40cm * 26.5cm * 6.5cm / 1.83kg
Outer Box Dimensions/Weight (1 Unit) 40.7cm * 28.6cm * 8.4cm / 2.12kg
Outer Box Dimensions/Weight (5 Units) 41.5cm * 36.5cm * 28.5cm / 10.2kg
Compatible Systems Windows/macOS/Android/iOS
Weight 645g (net), 1.45kg (gross)
Certifications CE/FCC/RoHS


Unit: mm



Mechanical Outline Drawing
FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle 0

Product Details

FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle 1FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle 2FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle 3FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle 4FHD 1920*1080 Portable Touch Monitor 15.6-Inch IPS Display for Flexible Display Modes and Wide Viewing Angle 5




Use Cases

Gaming & Entertainment

  • Console Gaming: Plug into PS5/Switch/Xbox for a second screen or portable gaming setup
  • Mobile Streaming: Mirror smartphone content (e.g., Netflix, YouTube) on the big touch screen
  • Touch Controls: Enhance gameplay on supported Windows games (e.g., touch-enabled emulators)

Productivity & Work

  • Dual Screen for Laptops: Extend workspace for coding, video editing, or multitasking
  • Interactive Presentations: Use touch functions for live annotations during meetings
  • Field Work: Portable solution for on-site data entry, design reviews, or customer demos

Mobile & Tablet Use

  • Samsung DeX/Huawei EMUI: Turn your phone into a mini PC with touch-enabled desktop mode
  • Tablet Extender: Use as a secondary touch screen for iPad Pro or Android tablets (via USB-C)

Compatible Devices List

Smartphones (Touch Supported on Windows Only)

  • Samsung: Galaxy S8/S9/S10/S20/S21/S22 series, Note 8/9/10/20, Z Fold/Z Flip
  • Huawei: Mate 10/20/30/40 series, P20/P30/P40/P50 series, Mate X2
  • Other: OPPO R17 Pro, LG V60, ZTE Axon 9 Pro (full-function USB-C required)

Laptops & PCs

  • Windows: Surface Book 2, De ll XPS 13/15, Lenovo ThinkPad X1 Carbon, HP Spectre 13 (Thunderbolt 3/USB 3.1)
  • Mac: MacBook Pro (2016+), MacBook Air (2018+)* (touch function not supported on macOS)
  • *Note: Touch features are disabled on macOS and ChromeOS.

Gaming Consoles

  • PlayStation 3/4/5, Xbox One/Series X|S, Nintendo Switch (via HDMI or USB-C)

Package Contents

  • 1x 15.6-inch Touch Portable Monitor
  • 1x USB-C to USB-C Cable (for power/video)
  • 1x Mini HDMI to HDMI Cable
  • 1x Power Adapter (100-240V)
  • 1x User Manual
  • 1x Adjustable Stand (integrated into monitor)
